RTMQ-320
RUITING
| PDF Export | |
Side-push label rotary die-cutting machines are ideal for various industries that require self-adhesive web die-cutting capabilities.
One of the standout features of this machine is its innovative side punch design. The die-cutting part adopts a side push method to facilitate the operator to replace the magnetic roller more conveniently.
In addition, our machines are equipped with Chinese and English switching interfaces, and users can choose according to their needs.
Advantage of our label rotary die-cutting machines is their convenient magnetic roller change system. When it comes time to replace the magnetic roller, our machines simplify the process, saving valuable time and effort. This feature is designed to increase the overall efficiency of the machine, ensuring uninterrupted production and minimizing downtime.
1.Efficient operation: It adopts advanced computer touch industrial control computer to provide intuitive graphic display and convenient operation interface.
2.Side push design: It is more convenient to replace the magnetic roller.
3.Auxiliary material discharge: Equipped with a mobile auxiliary material discharge shaft to improve operational flexibility.
4.Stable deviation correction: The main material discharge EPC deviation correction device ensures that the material enters the knife seat stably.
5.Break detection: Intelligent detection of breakage and automatic shutdown or alarm, effectively reducing material waste.
It is suitable for die-cutting industries such as tape, protective film, foam, mesh, copper and aluminum foil, backlight module, flexible circuit board, medical and health, to meet the high-precision die-cutting needs of different materials.
1. With meter and number counting.
2. EPC web guide system.
3.Auto Tension control system.
4.Control panel.
5.Transmission mode timing belt.
Slitting speed | 150m/min |
Max. web width | 320/420/520mm |
Max.cutting width | 310/410/510mm |
Die-cutting length | 178mm-476mm |
Max. unwinding diameter | 500mm |
Max. rewinding diameter | 500mm |
Cutting precision | ±0.1mm |
Total power | 8 KW |
Power voltage | 380V,3 Phase |
Overall dimensions | 3.3m*1.30m*1.65m |
Machine weight | 2000kg |
